No. Description Part No.
1
H
00
1
H Qty. No. Description Part No,
E>
1
H
00
1
H Qty,
1 PIN-cotter, 3/16 X 1 LM-09184-58 X X 2 24 BOLT-carriage, 3/8-16x3/4 LM-09221-10 X X 8
2 SHAFT ASSEMBLY-roller LM-16076-05
X X 1 25 LINK-mower lift LM-01081-99 X X 2
* 3 WASHER-flat (note ]) LM-01773-51 X X as req'd 26 WASHER-flat, 3/16 LM-09239-06 X X 2
4 ROLLER ASSEMBLY LM-01084-31 X X 4 27 PIN-lock LM-01530-58 X X 1
Includes: (each assembly) 28 SCREW-hex cap, 3/8-16 x 1 LM-09077-31 X X 1
5 BUSHING LM-010 84-19
X X
2 29 BAR-lift LM-16080-67 X X 1
6 SPACER LM-160 71-74 X X 5 30 CHAIN LM-01070-31 X X 1
7 BOLT“ shoulder LM-16021-86 X X 4 31 NUT-hex, 5/16-18 LM-09233-62 X X 1
8 WASHER-Hat, 7/16 LM-09184-30
X X 4 32 ROD-adjusting (R. H,) LM-16069-74 X 1
9 BAR-roUer LM-16032-63 X X 1 ROD-adjusting (R. H.) LM-16069-10 X 1
10 QUADRA NT-mower lift LM-16068-45 X X 1 33 ROD-adjusting (L. H.) LM-16069-73 X
1
11 SPRING-controI lever LM-16069-57 X X 1 ROD-adjusting (L. H.) LM-16069-09 X 1
12 WASHER-lock, 3/8 LM-09169-65 X X 15 34 NUT-hex jam, 1/2-20 LM-09192-62 X X 2
13 NUT-hex, 3/8-16 LM-0916 9-50 X X
15 35 BRACKET-mower, front (R. H.) LM-16069-81 X X
1
14 KNOB LM-16102-53 X X 1 36 SPACER-pivot LM-16069-56 X X 2
15 LEVER-control LM-16069-58 X X 1 37 PiN-rd.hd., 3/8 X 1-1/2 LM-01563-06 X X 2
16 PIN-cotter, 1/8 X 1 LM-09184-52 X X 6 38 LINK ASSEMBLY-mower LM-16069-62 X X 1
17 ARM ASSEMBLY-mower LM-16068-95 X X
1 39 SCREW-hex cap, 3/8-16 x 1-1/2 LM-09193-60 X X 2
18 YOKE-rod end LM-16073-25 X 2 *40 WASHER-flat, LM-07 77 3-54 X X 2
YOKE-rod end LM-01576-31 X 2 41 BRACKET-mower, front (L. H.) LM-16069-80 X X
1
19 PIN-quick LM-81610-45 X X 5 42 SCREW-hex, 5/16-18 x 1 LM-09164-31 X X
1
20 PIN-yoke, 1/2 LM-01543-05 X X 2
NOTE 1 - Minimum ot 9 reauired.
21 WASHER-flat, 3/8 LM-09173-78 X X 5
22 RING-retaining LM-01572-86 X X 2 * Denotes new parts
23 BRACKET-pivot LM-16068-44
X X
1
