Homelite S-4 User Manual
Page 10
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".
Part No.
Description
Qty.
Part No,
Description
Qty.
LM-01060-58
Chain w/conn. link
1
LM-01180-56
Grip-clutch
1
LM-01061-93
Shaft-intermediate
1
LM-01210-44
Pin-lock
1
LM-01061-99
Housing Assembly
1
LM-01211-07
Spacer
1
LM-01062-01
Lever Assembly
1
LM-01211-15
Shaft Assembly
1
LM-01062-04
Lever Assembly
1
LM-01211-18
Pinion-reverse
1
LM-01062-14
Pulley
1
LM-01211-39
Plate-lock
1
LM-01062-15
Plate-friction stop
1
LM-01211-63
Spacer-pinion
1
LM-01062-16
Bolt-frame
1
LM-01211-75
Liner-guide
1
LM-01062-17
Spacer-fra me
1
LM-01213-06
Gear Assembly
1
LM-01062-27
Pulley
1
LM-01510-40
Key
1
LM-01062-29
Nut-wing
2
LM-01520-50
Guide-rod
1
LM-01063-72
Clip-speed
3
LM-01530-11
Extens i on- s pr ing
1
LM-01064-51
Tire
2
LM-01530-78
Bearing
1
LM-01064-91
Bearing
1
LM-01530-79
Washer
2
LM-01065-33
Br acke t-hood
1
LM-01530-88
Washer
2
LM-0106'5-34
Hood Assembly
1
LM-01530-89
Bearings
2
LM-01065-37
Guard Assembly
1
LM-01530-94
Shield
1
LM-0106 5-40
Bracket-belt guard
1
LM-01531-05
Case-gear
1
LM-01065-41
Support-belt guard
1
LM-01531-06
Cover-gear case
1
LM-01065-45
Stop-belt
1
LM-01531-14
Gasket-bearing housing
1
LM-01065-58
Grip
2
LM-01531-15
Gasket-gear case
1
LM-01065-72
Grip
2
LM-01531-21
Spring-reverse lever
1
LM-01065-90
Shield-air intake
1
LM-01531-24
Ring-retaining
2
LM-01065-91
Bracket-air intake
1
LM-01541-19
Spring Clip
1
LM-01066-24
Stop-belt
1
LM-01541-77
Bushing
1
LM-01066-53
Sprocket-rotor
1
LM-01542-58
B e ar ing- ne edle
2
LM-01066-63
Pulley
1
LM-01543-07
Belt-"V"
1
LM-01067-32
Bearing-cartridge
2
LM-01545-34
Pulley-idler
2
LM-01067-47
Skid
2
LM-01583-96
Ring-retaining
2
DM-01067-60
Extension-spout
1
LM-01610-G9
Flange-bearing
4
LM-01067-62
Spout Assembly
1
LM-01610-90
Extens ion- spr ing
1
LM-01067-71
Stud
2
LM-01610-92
Cl amp-wire
1
LM-01067-74
Deflector
1
LM-01611-59
Rod Assembly
1
LM-01067-77
Guide-clutch wire
1
LM-01611-61
Wheel & Tire
2
LM-0106 7-7 8
Spring Assembly
1
LM-01611-62
Wheel
2
LM-01067-85
Washer-cup
1
LM-01611-63
Rod
1
LM-01068-22
Plate-support
1
LM-01611-64
Axle & Gear Assembly
1
LM-01068-23
Rotor Assembly
1
LM-01611-66
Bolt-shoulder
1
LM-01068-25
Support
1
LM-01611-67
Stud
2
LM-01068-26
Housing-bearing
1
LM-01611-68
Plate-locking
1
LM-01068-27
Shaft Assembly
1
LM-01611-69
Bar-clutch
1
LM-01068-29
Rod-clutch rotor
1
LM-01611-71
Housing Assembly
1
LM-01068-31
Scraper-body
1
LM-01611-76
Spring
1
LM-01068-66
Cover “belt
1
LM-01611-77
Control Assembly
1
LM-01068-80
Clip-speed
1
LM-01611-80
Body-frame Assembly
1
LM-01068-81
Cable Assembly
1
LM-01612-80
Liner
1
LM-01068-85
Nipple-pipe
1
LM-01707-54
Plate-side
1
LM-01084-18
Screw
1
LM-01708-65
Chain Guard
1
LM-01180-53
Pin
1
*LM-0l760-2o
Support
1
10
ALWAYS FURWISH MODEL AND SERIAL NUMBER WHEN ORDERING PARTS
* Denotes new parts
