R O T O R B O D Y a n d F R A M E
No.
Description
Part No.
Qty,
1
BODY-frame assembly
LM-01611-80
1
2
F LANGE-be ar ing
LM-01610-69
4
3
CARTRIDGE-bearing
LM-01067-32
2
4
SCREW-set, 1/4-28
X
1/4
LM-09286-92
4
5
SCREW-hex, 5/16-18 x 3/4
LM-09173-97
6
6
SCREW-set, 5/16-18 x 5/16
LM-09286-91
1
7
PULLEY
LM-01066-63
1
8
KEY
LM-09051-23
1
9
WASHER
LM-80610-12
7
10
GUARD-chain
LM-01708-65
1
11
WASHER-lock, 3/8
LM-09169-65
8
12
NUT-hex, 3/8-16
LM-09169-50
8
13
NUT-hex, 5/16-18
LM-09173-72
12
14
WASHER-lock, 5/16
LM-09173-56
12
15
SCREWyhex hd., 5/16-18 x 1-1/2
LM-09199-33
2
16
CLAMP, Hsg.
LM-01761-61
1
17
BEARING-needle
LM-01542-58
2
18
HOUSING-bearing
LM-01068-26
1
19
BOLT-carriage,, 3/8-16 x 3/4
LM-09160-61
4
20
SKID
LM-01067-47
2
21
WASHER-flat
LM-09173-78
8
22
SHAFT ASSEMBLY
LM-01068-27
1
23
CHAIN
LM-01060-58
1
24
NUT-hex, 3/8-16
LM-09234-28
2
25
NUT-flange, Whiz lock, 3/8-16
LM-09283-52
2
26
FITTING-grease
LM-09211-33
1
27
SCREW-hex, 3/8-16 x 1
LM-09077-31
1
28
NUT-Tinner man
LM-09286-99
1
29
SCREW-Self-Tap, #10 x 1/2
LM-09286-88
1
30
CLIP-speed
LM-01068-80
1
31
PLATE-side
LM-01707-54
1
32
SCREW-set, 5/16-18
X
5/16
LM-09286-91
1
33
SPROCKET-rotor
LM-01066-53
1
34
NUT-hex, 5/16-18
LM-09233-62
2
35
SCRAPER-body
LM-01068-31
1
36
WASHER-plain, 1/4
LM-09173-77
2
37
SCREW-hex, 5A6-18 x 5/8
LM-09252-05
2
38
NUT-hex, 1/4-20
LM-09157-41
4
39
WASHER-lock, 1/4
LM-09169-64
4
40
SCREW-hex hd., 1/4-20 x 5/8
LM-09219-59
4
41
KEY
LM-01510-40
1
42
ROTOR ASSEMBLY
LM-01068-23
1
43
SCREW-hex hd., 5/16-18 x 5/8
LM-09193-18
4
44
DEFLECTOR
LM-0106 7-74
1
45
STUD
LM-01067-71
2
46
SUPPORT
LM-01068-25
1
ALWAYS FURNISH MODEL AND SERIAL NUMBER WHEN ORDERING PARTS.
