Emerson EM-262 User Manual
Bluetooth'* wireless headset, Model: em262, Limited warranty
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".

O
Owner's Manual
O
Location of controls
4. Set your mobile phone to search for Bluetooth devices.
TM
©Bluetooth'*
Wireless Headset
Model: EM262
^
In the box
8a
About noise cancellation technology
This headset uses a
Dual Microphone Design
to filter out
wind and unwanted external noise.
Using Noise Cancellation technology, the headset compares
the sound from the twin built-in microphones, and is able to
recognize the difference between voice and unwanted
background noise.
^
^
.
Dual Microphone Design
Wind and unwanted bacl^round noise
are
filtered out enabling the other end of
your conversation to hear you clearlyl
Microphone 2
Power button
Power ON/OFF
Answer/end
Indicator light
Charging
Volume up
Volume down
Microphone 2 ^Microphone 1
within 3 feet
Bluetooth: Enabled
Paired Devices:
‘Empty ’
© Searching for devices
Charging the Bluetooth Headset
Before using your
Bluetooth Headset
for the first time, charge
it for 10-12 hours.
1.
Connect the smaller end of the USB cable to the charging
socket of the headset.
2. Connect the other end of the USB cable to either the:
• AC Charger, and plug into a wall (A/C) outlet.
• Computer's USB port.
• Car Charger
3. The
BLUE LED
indicator light turns on.
4. The
BLUE LED
indicator light shuts off when the headset
is fully charged (approximately
2-3
hours).
NOTE:
The
Bluetooth Headset
will emit an intermittent
beep tone when the battery is running low and requires
recharging.
5. When the phone finds the headset, confirm by selecting
it
from the list.
Bluetxioth: Enabled
Paired Devices:
6. Enter passcode"0000"when prompted by the phone.
Bluetooth: Enabled
Paired Devices:
Q
Enter
numeric
passkey
for EM262:
OK
NOTE:
Make sure you charge your headset for
10-12 hours
before using it for the first time.
^
Pairing the heaebetwith a Bluetooth enabled phone
1. Make sure the
Bluetooth Headset
is turned off.
2. Keep your
Bluetooth Headset
and mobile phone within
3
feet of each other during the pairing process.
3. Press and
HOLD
the
[POWER]
button until the
BLUE
indicator
light turns on, flashes several times, and becomes a steady
blue. The headset is now in
Pairing Mode,
and is ready to
connect to your mobile phone.
Power button
(Press &
HOLD)
Indicator light
0
Confirm
connection
to
EM2B2?
YES I/
8. When attempting to reconnect the headset to your mobile
phone,you may see the message below, and your mobile
phone will prompt you to accept the connection request to
the
EM262
headset, and an option not to ask this again.
Please accept the connection,and if you select"Don't ask this
again" your phone will automatically accept future connection
requests from your
Bluetooth Headset.
Bluetooth: Enabled
Paired Devices:
0
Accept
connection
request
from EM2B2?
YES
/
B Don't ask this again
NOTE:
To enter the
Pairing Mode,
you must press and
HOLD
the
power button for approximately 10 seconds.
Microphone 1
NOTE:
The screenshots above are typical of many Bluetooth enabled
phones in the market today, and are used to assist in the
explanation of the pairing process. Your mobile phone's
interface and interaction with the
Bluetooth Headset
may
slightly differ from the illustrations above.
8M
Using your Bluetooth Headset
Powering ON/OFF
• To turn
ON,
press and
HOLD
the
[POWER]
button until the
BLUE LED
indicator light turns on.
• To turn
OFF,
press and
HOLD
the
[POWER]
button until the
BLUE LED
indicator light flashes quickly several times, and
then turns off.
Power button
(Press &
HOLD)
Indicator light
Answering/Ending a call
• To answer a call, press and release the
[POWER]
button.
• To end a call, press and release the
[POWER]
button.
Power button
NOTE:
If your mobile phone is Bluetooth 2.1 compliant, you will
not need to enter a passcode, and can skip to step 7.
7. Your mobile phone will confirm that the pairing was completed,
and prompt you to accept the connection. Please respond
YES
to connect the headset to your mobile phone. If the pain ng
was successful, the headset's indicator light flashes a steady blue.
Bluetooth: Enabled
Paired Devices:
To make a call
Dial the number and press the send button on your mobile
phone, the call is automatically transferred to the headset.
Redialing the iast number caiied (Dependent
on your phone supporting this feature)
Double press the
[POWER]
button and release. The headset
will emit a confirmation beep tone, and the last number
called will be redialed.
Power Button
Double Press to redial
Adjusting the voiume
Press the
[VOLUME UP]
or
[VOLUME DOWN]
button to adjust
the volume to the desired level.
Volume up
NOTE:
You may also adjust the volume from your mobile phone's
volume control.
8M
Wearing your Bluetooth Headset
You may wear your headset with or without the provided
earhook. If you choose to wear your headset with the earhook,
connect it to the headset as shown in the diagram below.
Earhook
comfortably
Headset
on the same side ofthe body as your mobile phone
8Ba
Troubleshooting tips
I cannot get the
Bluetooth Headset
into
Pairing Mode
• Make sure the
Bluetooth Headset
is turned off before
beginning the pairing process.
• Press and
HOLD
the
[POWER]
button until the
BLUE
indicator light turns on,flashes several times, and becomes a
steady blue. This will signal that the headset is in
Pairing
Mode,and ready to connect to your mobile phone.
Mymobile phone is not able to pairwith the
Bluetooth Headset
• Make sure that you fully charged the headset before pairing.
• Keep your
Bluetooth Headset
and mobile phone within 3
feet of each other during the pairing process.
• Check that your phone's Bluetooth feature is turned
ON.
• Try repeating the pairing process, see "Pairing the headset
with a Bluetooth enabled phone."
© After successfully pairing my mobile phone and
Bluetooth
1
Headset,
when I shut my phone and turn it on again, my
^ headset did not automatically connect_____________________
y
' Try turning the headset
OFF,
and then turning it
ON
again.
' Many mobile phones have an auto reconnect option when first
attempting to reconnect to a newly paired Bluetooth device.
Make sure you accept this option, so that your
Bluetooth Headset
automatically reconnects to your mobile phone; check the user
guide of your mobile phone for more information regarding
this option.
' Try unpairing the headset from your phon^and repeat the pa i ri ng
procedure
I hear distortion, and the sound quality is poor
For the best audio quality, always wear your
Bluetooth Headset
on the same side of the body as your mobile phone.
Check that the battery is charged enough.
^^The sound is very low
Try adjusting the volume by using the
[Volume]
button on your
headset; make sure the volume on your mobile phone is
turned up as well.
Drive Safe
Driving while talking on your mobile phone is dangerous,and
illegal in many states.
Although this device enables drivers to conduct handsfree
conversations, it is still dangerous to drive and use a mobile phone
at the same time.
We recommend pulling over before making or answering calls,
especially during adverse driving conditions. Please use your
mobile phone,and our product responsibly while driving!
8Bd
Safety information
•
Check local laws regarding use of a mobile handset and wireless
headset while driving. If you use the
Bluetooth Headset
while
drivi ng, ensure your attention and focus remains on your driving.
* Observe all signs in the designated areas where some electronic
devices or RF radio products are required to be switched off.
These could include airplanes, hospitals,blasting areas,and
potentially explosive atmospheres.
A
CAUTION:
Although this device enables drivers to
conduct handsfree conversations, it is still dangerous
to drive and use a mobile phone at the same time.
Always keep your full attention on your driving.
1^
Product maintenance
• Power off this product when not in use.
• DO NOT expose this product to water or other liquids.
• DONOTuseabrasivedeaningsolventstodeantheBluetoothHeadset
• If you will not use the
Bluetooth Headset
for long periods^ be sure to
store it in a dry plac^fieefiom extreme temperature humidity and dust
FCC and telephone company information
FCC Part 15
This equipment has been tested and found to comply with the
requirements for a Class B digital device under Part 15 of the
Federal Communications Commission (FCC) rules. These
requirements are intended to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more ofthe following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Do not attempt to repair or modify this equipment.
Warning:
Changes or modifications to this equipment not
expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
8Ba
Industry Canada
Operation is subject to the following two conditions: (1) This
device may not cause interference and (2) This device must
accept any interference, including interference that may
cause undesired operation ofthe device.
The term "1C:" before the certification/registration number
only signifies that registration was performed based on a
Declaration of Conformity indicating that Industry Canada
technical specifications were met. It does not imply that
Industry Canada approved the equipment.
8M
Warranty information
Limited Warranty
In the unlikely event that this product is defective, or does
not perform properly, you may within
one (1) year
from
your original date of purchase return it to the authorized
service center for repair or exchange.
TO OBTAIN WARRANTY SERVICE:
• Provide proof of the date of purchase within the package
(Dated bili of saie).
• Prepay aii shipping costs to the authorized service center,
and remember to insure your return.
• Include a return shipping address (no P.O. Boxes),
a telephone contact number, and the defective unit within
the package.
• Describe the defect or reason you are returning the product
Your product will be repaired or replaced, at our option, for the same
or similar model of equal value if examination by the sen/ice center
determines this product is defective. Products received damaged
as a result of shipping will require you to file a claim with the carrier.
The shipping address ofthe authorized service center is:
^ Southern Telecom Inc.
ATTN: Returns Department
14-C 53rd Street
Brooklyn, NY 11232
Should you have any questions or problems concerning this
product, please contact our customer service department at:
01-877-768-8483 (Toll Free)
Monday - Thursday: 9AM - 5PM (EST)
Friday: 9AM-3PM (EST)
or
via e-maii at
Warranty service not provided
This warranty does not cover damage resulting from accident,
misuse, abuse, improper installation or operation, lack of reasonable
care, and unauthorized modification. This warranty is voided in
the event any unauthorized person opens, alters or repairs this
product. All products being returned to the authorized service
center for repair must be suitably packaged.
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY
APPLICABLE TO THIS PRODUCT. ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) ARE
HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION
GIVEN BY SOLITHERN TELECOM INC. ITS AGENTS, OR EMPLOYEES
SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE
SCOPE OF THIS WARRANTY.
• REPAIROR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY
IS THE EXCLUSIVE REMEDY OF THE CONSUMER. SOUTHERN
TELECOM INC. SHALL NOT BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS
PRODUCT OR ARISING OUT OF ANY BREACH OF ANY EXPRESS
OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER
OF WARRANTIES AND LIMITED WARRANTY ARE GOVERNED
BY THE LAWS OF THE STATE OF NEW YORK. EXCEPT TO THE
EXTENT PROHIBFTED BYAPPUCABLE LAW, ANYIMPUEDWARRANTY
OF MERCHANTABILFTY OR FTTNESS FOR A PARTICULAR PURPOSE
ON THIS PRODUCT IS LIMITED TO THE APPLICABLE WARRANTY
PERIOD SET FORTH ABOVE.
Some states do not allow the exclusion nor limitation of incidental
or consequential damages, or limitations on how long an implied
warranty lasts so the above limitations or exclusions may not apply
to you. This warranty gives you specific legal rights, and you also may
have other rights that vary from state to state.
Distributed by: AIT Inc. Brooklyn, NY 11232
© 2009 AIT Inc. All rights reserved.
Emerson and the G-Clef logo are registered trademarks of
Emerson Radio Corp. Parsippany, New Jersey USA.
Tire Bluetooth^’v\/ord markand logos are owned by the Bluetooth SIG, Inc
