The numbers in parentheses indicate the pages where each item is explained.
.
Camera
General Guide
1 Shutter button (page 24)
2 [ON/OFF] (Power)
(page 23)
3 Flash (page 35)
4 Front lamp
(pages 27, 62)
5 Lens
6 Microphone
(pages 49, 79)
7 Back lamp
(pages 23, 25, 35)
8 Zoom button
(pages 24, 45, 72)
bt Battery/memory card slots (pages 17, 21, 128, 130)
ck Tripod hole
Use this hole when attaching to a tripod.
cl Speaker
3 4 2 1
5
6
8 7 9 bk
bl
bm
bo bp bq br bs bn
[ ]
[ ]
[ ]
[ ]
[SET]
Front Back
ck cl
bt
Bottom
9 Strap hole (page 2)
bk Connector cover
bl USB/AV port
(pages 73, 82, 89, 98)
bm [r] (REC) button
(pages 23, 24)
bn [SET] button (page 31)
bo [BS] button (page 52)
bp [MENU] button
(page 55)
bq Control button
([8] [2] [4] [6])
(pages 29, 31, 35, 118)
br [p] (PLAY) button
(pages 23, 28)
bs Monitor screen
(pages 10, 118)
