F I N I S H
Housing and arm finished in a 5 stage
premium TGIC polyester powder coat
paint, 2.5 mil nominal thickness for
superior protection against fade and
wear. Standard colors include black,
bronze, grey, white, dark platinum,
and graphite metallic. RAL and custom
color matches available. Consult the
McGraw-Edison Architectural Colors
brochure for the complete selection.
M O U N T I N G C O N F I G U R A T I O N S
Talon is available in seven [7] unique luminaire mounting configurations.
NOTE: In Flat Glass configurations only.
D R I L L I N G P A T T E R N S
Type “M”
Wall Mount
3/4" [20mm]
dia. hole
[2] 5/8" [16mm]
dia. holes
4 7/8" [124mm]
2 7/16" [124mm]
2 5/16"
[59mm]
12"
[305mm]
4 7/8"
[124mm]
9/16" [14mm]
Dia. Hole [4]
6 1/2"
[165mm]
8"
[203mm]
10 1/2"
[267mm]
IP65 Rated
CSA Listed
Certifications
U.L. 1598 Listed ISO 9001
25°C Ambient
GM
Graphite Metallic
WH
White
DP
Dark Platinum
BZ
Bronze
BK
Black AP
Grey
Wall Mount Arm Mount Single
E.P.A.
TLM
Recessed Door 1.22
Deep Door
1.45
TLL 2.51
Arm Mount 2 @ 180°
E.P.A.
TLM
Recessed Door 2.44
Deep Door
2.90
TLL 5.02
Arm Mount 2 @ 90°
E.P.A.
TLM
Recessed Door 2.44
Deep Door
2.90
TLL 5.02
Arm Mount 3 @ 120°
E.P.A.
TLM
Recessed Door 3.23
Deep Door
3.92
TLL 6.85
Arm Mount 3 @ 90°
E.P.A.
TLM
Recessed Door 3.23
Deep Door
3.92
TLL 6.85
Arm Mount 4 @ 90°
E.P.A.
TLM
Recessed Door 3.63
Deep Door
4.43
TLL 7.77
