□ Make sure the shaving head is always in full
contact with your skin.
B Turn Groomer OFF by pressing the on/off
button (Fig. 10).
Shaving with the back shaving attachment
D
Press the release button (1) and open the
back shaving attachment (2) (Fig. 11).
B Place the Groomer in the lower part of the
holder of the back shaving attachmenL
B
Press the top against the top part of the
holder until it locks into place with a click
(Fig. 12).
□ Turn Groomer ON and shave your back by
moving the back shaving attachment up and
down by the handle (Fig. 13).
Note: The back shaving attachment handle can be
folded to different angles (Rg. 14).
B Remove the Groomer from the back shaving
attachment by pulling the top of the
Groomer toward you until it releases from
the holder (Fig. 15).
□ Press the release button (1) and push the
handle against the holder (2) to close the
back shaving attachment (Fig. 16).
Cleaning
I The Groomer should be cleaned after each use.
I Ahvays switch Groomer OFF and remove
power cord from charging stand and outlet
before cleaning.
I Do not use compressed air. abrasive
cleaning agents, scourers or aggresive liquids
such as gasoline, alcohol, benzene bleach or
acetone to clean the appliance.
I Never clean, remove or replace shaving head
assembly while motor is on.
I Do not apply pressure to shaving head. Do not
touch foil with hard objects as this may dent or
damage foil or cutters. If damage occurs, replace
damaged parts.
I Do not use Groomer if foil, cutters, trimmers
or combs are damped or broken as injury
may occur.
I Only use the cleaning brush supplied. Any other
brush may cause damage.
Cleaning the shaving unit
D
Always switch Groomer OFF, remove the
power cord from outlet and charging stand
before cleaning.
Q Remove any trimming comb from Groomer
(Fig-9).
B Remove the shaving head by pulling it off
the appliance (Fig. 17).
Hold the shaving head by the plastic housing only.
□ Rinse the shaving head under warm running
tap water to rinse away debris (Fig. 18).
Do ''.ot use toe-deaninfi brus-^.Ao_dean Uie.
snaving head as this may cause damage to the foil
or cutters.
B Place the new shaving head on the Groomer
by snapping it into place (Fig. 20). You will
hear a "click”.
After replacing the shaving head, check that
the shaving head is firmly attached before using
Groomer
PHILIPS
B Clean the hair chamber with the cleaning
brush. You may also rinse the hair chamber
under warm running cap water to remove any
residual debris (Fig. 19).
B Do not use a towel or cloth to dry shaving
foil or cutters as this may cause damage: allow
to air dry thoroughly.
B
Reattach the shaving head by snapping it back
onto the Groomer (Fig. 20).
B Rinse the Groomer body and back shaving
attachment under running warm tap water.
Wipe dry with a soft clean towel or cloth.
Replacing the Shaving Head
I If the shaving foil and cutters are worn or
damaged, do not continue using the Groomer.
Replace the shaving foil and cutters immediately.
I It is recommended that you replace your
shaving foil and cutters once a year.
IA worn or damaged shaving foil or cutters
should only be replaced with an original Philips
Norelco shaving head, model BG2000. which is
available on the Philips Norelco website.
www.philips.com/support or call
1-800-243-3050 for assistance.
I The foil is a precision part. Handle with care.
This Groomer has no other user-serviceable part-
For assistance call 1-8Q0.243-3050.
Storage
I Be sure Groomer is turned off. Remove
power cord from oudet and charging stand
before scoring in a safe, dry location where it
will not be crushed, banged, or subject to
damage.
^ Do not wrap power cord around Groomer/
charging stand when storing.
I Score cord in a safe location where it will not
be cut or damaged.
I Do not place or score Groomer/charging stand
where it can fall or be pulled into a tub or sink,
water or ocher liquid while plugged in.
Battery Removal
I This Philips Norelco Groomer contains
a Lithium-Ion rechargeable battery
which must be disposed of properly (Fig. 21).
I Battery should only be removed when
Groomer is to be discarded.
I For assistance, call toll free: 1-800-243-3050
or visit our website. www.philips.com/supporL
□ Be certain Groomer is OFF and removed
from charging stand before dismanding.
Allow the Groomer to run until the batteries
are completely empty/depleced. Turn
Groomer OFF.
B Insert a flathead screwdriver into the slot at
the bottom of the handle and turn it to
unlock the rear panel of the housing (Fig. 22).
B Remove the rear panel of the housing and
then remove the side panels (Fig. 23).
□ Undo the screws that connect the inner
body of the appliance to the front panel of
the housing and separate the inner body
from the front panel (Fig 24).
B Turn over the inner body.Then detach the
cover of the inner body with the control
panel from the inner body (Fig. 25).
□ Lift the printed-circuit board out of the inner
body, turn it over and cut the wires that
connea the battery to the power unit
(Fig. 26).
B
Do not attempt to replace batteries. Insulate
battery ends by covering with tape and/or
place battery in a small plastic bag.
□ Discard Groomer. Do not attempt to plug
elearical cord into the outlet or recharge
Groomer after the batteries have been
removed.
D Contact your local town or city officials
for battery disposal information or call
1-800-8-BATTERY or www.rbrc.com for
drop-off locations.
Assistance
For assistance, visit our website:
www.philips.com/support or
call 1-800.243-3050
Online information is available 24 hours a day.
7 days a week.
Accessories
I For maximum Groomer performance replace
shaving head once a year.
I Replacement Shaving Head
Model BG2000-Philips Norelco Replacennent
Shaving Head
t Replacement Parts may be purchased on
our website www.philips.com/store
^NORELCO
Bodygroom
System
BG2038
Rechargeable
Cordless
Always here to help you
Register your product and get support at
www.norelco.com/register
4222 002 8263 3
PHILIPS
^NORELCO
45-DAY MONEY-
BACK GUARANTEE
If you are not fully satisfied with your Philips Norelco
Groomer send the product back and we’ll refund you
the full purchase price.
The Groomer must be shipped prepaid by
insured mail, insurance prepaid, have the original
sales receipt, indicating purchase price and date
of purchase, and the money-back guarantee
return authorization form enclosed. We cannot
be responsible for lost mail.
The Groomer must be postmarked no later
than 4S days after the date of purchase. Philips
Norelco reserves the right to verify the purchase
price of the product and limit refunds not to
exceed suggested retail price.
To obtain money-back guarantee return
authorization form, call 1-800-243-3050 for
assistance.
Delivery of refund check will occur 6-8 wreeks AFTER
receipt of returned product
Full Two-Year Warranty
R'ips Electronic North Ametia Corporaoon warants cich new
Norelco pnxlict Model 9G2038 (except foi cutters and сопС») against
defects n mneruJs or Mortmansho Ibr a penod of two years from the
date of purctuse. and agrees to repar or repbee any defcetne product
wnhout г-.-гд.-
IMPORTANT: the warranty does not coser damage resuHx^g from
acodent. mouse or abase, lade of reasonable care, the af(xr^ of any
attachment not pro»flded with the product or loss of parts or sub|ccting
ihe piodjcl to any but the speoAed NcVtage.* Use of unauthorued
replkemert parts w4 vod the warranty.
PHILIPS ELECTRONICS NORTH AMERICA CORPORATION
WILL NOT PAY FOR WARRANTY SERVICE PERFORMED BY
A NON'AUTHORIZED REPAIR SERVICE AND WILL NOT
REIMBURSE THE CONSUMER FOR DAMAGE RESULTING FROM
WARRANTY SERVICE PERFORMED BY A NON-AUTHORIZED
REPAIR SERVICE.
NO RESPONSIBILITY IS ASSUMED FOR ANY SPECIAL.
INCIDENTAL OR CONSEQUENTIAL DAMAGES.
In order to obtan warrarty serve«. smpV 9^ to wwwpM^conV
norelco or call 80D 243 3360 (or assstance.il »suggested that (or
>our protecMn you retxm shpmenb of prodxt by nsured mai
nsurance prepaid. Damage occu-nng dawg sbpment is not covered by
tNs wan-anty МОТЕгМооФег war-arcywmen ororat isauthonred
by №Bps ClectronKS North America Coiponbon Tbs warranty pves
>ou ^ecific legal nghts. and >ou may also hare other ngNs which vary
from state to state. Some states do not allow the cxcluson or Imtabon
of nodeniaJ or соп$е<ьепы1 damages, so the above exclusion and
Imtations may not ap^ to you.
*ftead endosed rsbuctions carefufy-
Manufacturd for:
№4ps Cormaner lifestyle
A Division of Pbiips Dectroncs North Amenca Corporation
RO BoK 10313.St»rdord.a 06904
(^^ this symbol on the prodjclsnimepiaCeniMns 4 s
hard by l ihdnvwlIrvV I .^of Jtonrv He
Nonelio s a Pegstered 1г«0«пи1 o( Hdps Uectrcncs
Nortli Amnxa СдгрогаЬэт
n ■ PS is a Reported Tradenwk cf KonrU^ PNips NV
C ХЛЗ НаЦмНггеопки Nsih Ашетка (avpsAan AJ Rpih Rrvswd
O
Always switch Groomer OFF and remove
Groomer from the charging stand before
replacing shaving head.
B Remove the shaving head by pulling it off
the appliance (Fig. 17).
