Form 0-772 Rev. 2
ENGLISH
PRO Wireless Animation Weather Station
FEATURES:
• Animation weather forecast: Sunny, Partly Sunny, Cloudy, Rainy
• Day of week in 7 languages: English, German, French, Italian, Spanish, Dutch and Danish
• Outdoor temperature and humidity with RF sensor – links up to 3 – 1 sensor included
• In/out temperature and humidity trend indicator
• Comfort index indicator
• Alarm/snooze function
• 12/24 hour selectable clock
• Moon phase indicator
SPECIFICATIONS:
Temperature range main unit
0 to 50°C (32 to 122°F)
Temperature range remote sensor
-50 to 70°C (-58 to 158°F)
Temperature resolution
0.1°
Humidity range
20 to 95% RH
Humidity resolution
1% RH
Sampling time
12 seconds
RF transmission frequency
433 MHz
Battery
2 AA batteries for main unit; 3 AAA batteries for remote sensor (included)
Battery Installation
This device is designed for easy set up. The following steps are required to be done in the proper sequence. Please insert batteries for the
receiving unit before the remote sensor
1. Press and slide to open the battery cover at the back of the unit. Insert 2 AA batteries according to the polarity marks inside the
battery compartment
2. Close the battery cover
3. Once you have properly installed the batteries, the LCD display will show the full display for 3 seconds and enter the normal mode
after the beep sound. The time will default to 0:00 and calendar to January 1. The alarm will default to 0:00, the weather icon will
default to partly sunny. The temperature scale will default to °C. The time system will default to 24 hours.
Wireless Remote Sensor Registration Procedure
1. Lift off the bracket stand of the remote sensor by sliding the bracket
2. Use a Phillips head screwdriver to remove the screws on the battery cover
3. Insert 3 AAA batteries according to the polarity markings on the battery compartment
4. Once the batteries are inserted, the sensor will start transmitting temperature readings for 3 minutes
5. The receiving unit will display remote channel 1 and the temperature reading
6. While in the normal display mode, holding down the “CHANNEL” button for 2 seconds will clear the channel information
7. After registration is completed for sensor 1, put the rubber seal into the cover groove, close the battery cover, tighten the screws,
and slide on the bracket stand. Follow the same procedure if installing additional remote sensors.
NOTE:
After you have placed the sensor in the remote location, observe the receiving unit channel display for that sensor after 35 minutes. If the
(--) dash icon is flashing for channel one, the signal has been lost, try rotating the sensor in 45° steps, wait for at least 3 minutes after
each position change. Observe the receiving unit channel display on each position to determine that the remote temperature display has
been restored, if not, move the remote sensor closer to the receiving unit or reposition both the receiving unit and the remote sensor until
reception is observed.
Setting 12 or 24 Hour Time Format
Quickly press the “UP” button to change the time from 0:00 to AM 12:00
Setting the Time, Calendar and Language
1. Press & Hold “SET” button for 2 seconds until you hear a beep – to enter into time setting
2. The sequence of time setting is: Year (2000-2050)MonthDateLanguageHourMinuteTime ZoneExit
3. Press “UP” button one time to advance the setting one step; hold “UP” button for 2 seconds and it will advance the setting by 8
steps/second
4. Press “DOWN” button one time to reverse the setting one step; hold “DOWN” button for 2 seconds and it will reverse the setting by
8 steps/second
5. Press “SET” button to confirm the setting and enter into the next setting state
6. The system will automatically exit if no key is pressed in 8 seconds
Setting the Alarm
1. Press & Hold “ALARM” button for 2 seconds – to enter into time setting
2. The sequence of alarm setting is: HourMinuteExit
3. Press “UP” button one time to advance the setting one step; hold “UP” button for 2 seconds and it will advance the setting by 8
steps/second
4. Press “DOWN” button one time to reverse the setting one step; hold “DOWN” button for 2 seconds and it will reverse the setting by
8 steps/second
5. Press “SET” button to confirm the setting and enter into the next setting state
6. The system will automatically exit if no key is pressed in 8 seconds
7. To turn on the alarm, quickly press the alarm button. A bell icon will appear in the upper left hand of the time display.
8. To turn off the alarm, quickly press the alarm button again. This will remove the bell icon from the display.
NOTE:
The buzzer will ring as follows:
0-10 second: one beep per second
10-20 seconds: two beeps per second
20-30 seconds: four beeps per second
after 30 seconds: will continuously beep
Snoozing the alarm
• Press “SNOOZE” button once to enter into 5 minutes of snoozing
• Pressing any other key will turn off the alarm
