5
W415-0514 / 05.30.05
As long as clearance to combustibles is kept
within the required distances, the most desirable
and benefical location for a Continental stove is
in the centre of a building, thereby allowing the
most efficient use of the heat created. The loca-
tion of windows, doors and the traffic flow in the
room where the stove is to be located should be
considered. If possible, you should choose a lo-
cation where the vent will pass through the house
without cutting a floor or roof joist.
Provide adequate ventilation and combustion air.
Provide adequate accessibility clearance for servicing and operating the stove.
Never obstruct the front opening of the stove.
Objects placed in front of the fireplace must be kept a minimum of 48" away from the front face of the unit.
FIGURE 1
WINDOW OPENING
16-7/8"
14-1/8"
28¼" 4"ø
FLUE
7"ø
AIR INTAKE
21-5/8"
8"
13-3/4"
11"
30-3/4"
21"
GAS LINE LOCATED
IN PEDESTAL REAR
LOCATION & CLEARANCES
CDVS500 AND CS500
