15
W415-0514 / 05.30.05
When opening the fire viewing door, a simple procedure
must be followed in order to not damage the door. First
open the valve control door. Next open both side doors
fully. Pull the latch handles towards you and release each
catch. The door may now be safely opened. To close the
door, repeat in reverse order.
There may be instances that require adjustment of the
door latches. To do this simply loosen the tighten the catch
until both latches snap closed when closing the door.
FIGURE 36
FIRE VIEWING DOOR
SIDE DOOR
VALVE CONTROL DOOR
SIDE DOOR
HANDLE
CATCH
FIGURE 37
FINISHING
ALL MODELS
DOOR OPENING AND CLOSING TRIVET INSTALLATION
Insert the trivet into the space on the stove top.
