INSTALLATION INSTRUCTIONS FOR 2-WIRE
AUTO START CONTROL CONVERSION
The following instructions are provided to convert the ULPSS15B4W/E
from a special 4-wire start system to a standard 2-wire Auto Start Sytem.
Items required:
WINCO Conversion Kit # 16448-005 Auto Start (for ULPSS15B2W/E)
T25 Torx Screwdriver
7/16” End Wrench or Socket & Driver
PROCEDURE
1. Move the left hand toggle switch “A”
to the “STOP” position.
2. Remove the battery negative (-)
cable if the battery is installed.
3. Unplug the wiring harness “D”.
4. Remove the two bolts “B” and remove
the circuit breaker cover panel “E”.
5. Remove the 4 torx screws “G” from the
tower assembly.
6. Remove the 4-wire controller “C” by
pulling it forward.
7. Install 2-wire controller “F” by pushing
the controller back into position.
8. Re-install the 4 torx screws “G”.
9. Re-connect the wiring harness “D”.
