2 3058-03 699-026I
Open hardware bag and account for all fasteners and components.
FASTENERS & MISC. COMPONENTS
(not shown in actual size)
•
FASTENER & COMPONENT LIST
REF #
PART # DESCRIPTION QTY
9 6343-000 Axle Shaft Protector 2
0 64688-007 Spacer 2
209-000 Shock Mount 2
2 64327-000 Hubcap 2
3 93402-00 Hole Plug 2
4 78-000 Flat Washer 2
5 96286-006 Nylon Flat Washer 2
6 57523-000 5/6”-8 X 3” Bolt 2
7 56842-004 3/4” Carriage Bolt 2
8 4757-000 /4”-20 Nylock Hex Nut 2
9 420-00 #0-24 X 3/4” Screw 4
20 6248-000 /4”-20 Flange Nut 2
2 466-000 /4-20 X 3/4” Bolt 2
22 467-000 5/6”-8 X 3/4” Bolt 8
23 526-000 Flat Washer 0
24 9967-000 #0-24 Hex Nut 4
25 6249-000 5/6”-8 Flange Nut 0
26 6292-000 /2” Foam Strip
STEP 1
9
10
11 12 13
14
15
17
25
18
19
20
21
22
23
24
16
26
