Winco 2-Wheel Dolly Kit Assembly Instructions - Manual (Page 4)

4 206-0 6204-005I
STEP 4
STEP 5
Place axle bracket (ref. 4) under the cradle and attach using bolts (ref. 6), nuts
(ref. 0) and lock washers (ref. ).
Remove and discard axle protectors (ref. 6). Tap one hubcap (ref.2) onto axle
(ref. 2) using a rubber mallet. Slide washer (ref. 3), wheel (ref. ), washer (ref.
3) and spacer (ref. 8) onto axle (ref. 2). Then slide assembly through axle brack-
et. (ref. 4) Place other spacer, washer, wheel, washer and hubcap on axle.
Remove the blocks under the gen-set. Tap the other hubcap (ref. 2) onto the
axle. NOTE: Do not tap too hard as you may dent the hubcaps.
•
•
•
Winco Inc.
Service Dept.
507-357-683
Attach leg support and handle assembly to the cradle using bolts (ref. 8), lock
washers (ref. ) and nuts (ref. 0). Repeat for other leg support and handle as-
sembly.
•
