Open hardware bag and account for all hardware and fasteners.
FASTENERS & MISC. COMPONENTS
(not shown in actual size)
•
STEP 1
HARDWARE & FASTENER LIST
REF. # PART # DESCRIPTION QTY.
7 64325-00 Rubber Grip 2
8 64688-005 Axle Stub 2
9 209-000 Bumper 2
0 458-000 5/6” - 8 Hex Nut 6
480-000 5/6” Lock Washer 6
2 64327-000 Hub Cap 2
3 78-000 3/8” Flat Washer 4
4 2586-002 /2” Flat Washer 2
5 5967-000 Tube Clamp 2
6 57523-000 5/6” X 3” Bolt 2
7 639-000 /4” - 20 X /2” Bolt 2
8 47-000 5/6” X 2 /4” Bolt 4
