Wilson Audio WATT Series 7 - Manual (Page 59)

W a T T / p
u p
-
p y
s
y s T e m
6 . 0 s
e T u p
4-5
P
uPPy
T
Ail
c
onnecTion
The correct connection of the Puppy Tail in the WATT/Puppy system 7 is:
• Connect the other RED lug at the load end of the tail to the RED
terminal on the WATT.
• Connect the other BLACK lug at the load end of the tail to the BLACK
terminal on the WATT.
Note: Please resist the temptation to invert the polarity of the Puppy Tail in the
WATT/Puppy System 7. Such an inversion will produce entertaining ambient ef-
fects, but destroys the linearity and harmonic structure of the system.
