Technical data
We reserve the right for technical modification without prior note!
VACUUBRAND GMBH + CO KG
-Technology for vacuum systems-
© 2013 VACUUBRAND GMBH + CO KG Printed in Germany 999189
The level sensor is adjusted at the factory on a coated VACUUBRAND catchpot 500 ml. Readjustment
of the level sensor might be necessary using an individual catchpot.
Fix the sensor on an empty (VACUUBRAND) catchpot as close as possible.
Controller CVC 3000: Choose ”Defaults On”.
Controller VNC 2: Press key ”Esc” while switching on and choose a factory set configuration.
The readjustment is than made automatically for both controllers. Attention: When choosing a factory set
configuration all individual settings are reset to factory set values.
Adjustment
Alfred-Zippe-Str. 4 - 97877 Wertheim
T +49 9342 808-0 - F +49 9342 808-5555
E-Mail: [email protected]
Web: www.vacuubrand.com
Type 699908 / 699909
Measuring principle capacitive sensor with digital evaluation
Adjustment
at the factory on a coated VACUUBRAND catchpot
500 ml (cat.-no.: 638497)
Sensitivity
adjusted to liquids with a dielectric coefficient
ε
r
> 1.8
Integration time until release 10 s
Reset time 2.5 s
Power supply 8V DC to 30V DC, typical 24V DC
Current draw < 5 mA
Output signal VACUU•BUS
Max. permitted ambient temperature at
operation / storage
+10°C to +40°C / -10°C to +60°C
Max. permitted relative atmospheric moisture
during operation
30 to 85%, no condensation
Degree of protection according to IEC 529 IP 65
Connection cable approx. 2m, VACUU•BUS
Dimensions housing L x W x H
(without cable, clip, mounting plate)
50 mm x 50 mm x 30 mm
Weight approx. 0.1 kg
Materials PA / PP / TPE / PE coated spring steel
