VACUUBRAND RZ 8 - Manual (Page 9)

Documents are only to be used and distributed completely and unchanged. It is strictly the users´ responsibility to check
carefully the validity of this document with respect to his product. Manual-no.: 99 90 77 / 17/04/2008
page 9 of 20
RE 2 / RZ 2
(fig. RZ 2, pump RE 2 with different terminal box)
RE 5 / RZ 5
oil inlet
oil outlet
manual gas
ballast valve
rating plate with mark
Min. / Max. for oil
level
on/off switch
inlet
outlet
handle
sight glass for oil level
inlet
outlet
handle
sight glass for oil level oil inlet
outlet
manual gas
ballast valve
rating plate with mark
Min. / Max. for oil
level
on/off switch
