page 10 of 20
RE 8 / RZ 8
RE 16 / RZ 16
rating plate with mark
Min. / Max. for oil
level
inlet
outlet
oil outlet
on/off switch
for electromag-
netic gas
ballast valve
on/off switch
handle
sight glass
for oil level
oil inlet
handle
sight glass
for oil level
oil inlet
rating plate with mark
Min. / Max. for oil
level
inlet
outlet
oil outlet
on/off switch
for electromag-
netic gas
ballast valve
on/off switch
