ANATOMY OF THE SLASH VXL
Motor
(Velineon 3500)
Transmission
Spur Gear
(under gear cover)
Pinion Gear
(under gear cover)
Rear Bumper
Slipper Clutch
(under gear cover)
Electronic Speed
Control (VXL-3s)
Battery Compartment
Battery
Nerf Bar
Battery Hold-Down
Receiver Box
LED Light Pipe
Antenna Mount
Suspension
Arm (Front)
Front Bumper
Steering Servo
Shock
(Oil Damper)
Turnbuckle
(Toe Link)
Turnbuckle
(Front Camber Link)
Turnbuckle
(Rear Camber Link)
Rear Shock Tower
Traxxas High-
Current Connector
Rear
Body Mount
Chassis
Steering Block
Caster Block
Front Body
Mount
Front Shock
Tower
Half Shaft
Suspension Arm (Rear)
