Page 4: Using the handle cap

6. HOW TO USE
Step 1. Using the volume control, adjust the volume
to an appropriate level that does not
generate feedback when holding down the
talk switch.
Howling is more likely to occur when using
the megaphone indoors and other spaces
with significant echo. Particularly when the
batteries are new, it may be impossible to
adjust the volume to maximum without
causing howling. In such cases, set the
volume to about mid-level.
Step 2. Speak into the mouthpiece at a distance of
about 1 cm.
Notes
• Speaking too far from the mouthpiece or in
too soft voice may result in insufficient
volume.
• Moisture droplets collecting in the hole on
the mouthpiece may cause noticeably
insufficient volume. Wipe the droplets away
with a cloth or other material and allow the
area to dry sufficiently before resuming
use.
8. SPECIFICATIONS
• Accessories
Battery spacer
(ER-1206 series only) ................ 1
Handle cap ................................. 1
• Optional products
Wall mounting bracket: SP-1100
*
1
With use of the supplied battery spacer
*
2
Battery life estimates assume 30 minutes of continuous use per day.
*
3
Audible range estimates assume use on a relatively quiet street using new
batteries and will vary depending on remaining battery capacity, surrounding
noise, wind direction, obstacles and other environmental conditions.
Notes
• No accessory batteries are supplied.
• The design and specifications are subject to change without notice for
improvement.
Model No.
ER-1203
ER-1206
ER-1206S
ER-1206W
Output
Rated 3 W, Max. 4 W
Rated 6 W, Max. 10 W (with use of AA (R6P) battery x 6)
Power Source
AA (R6P) battery x 4 (6 V DC)
AA (R6P) battery x 6 (9 V DC) or AA (R6P) battery x 4*
1
(6 V DC)
Signal
–
–
Siren
Whistle
Battery Life*
2
Voice: 8 hours
[With use of AA (R6P) battery x 6]
(approx.)
Voice: 8 hours
Voice: 8 hours, Signal: 20 minutes
[With use of AA (R6P) battery x 4]
Voice: 5 hours
Voice: 5 hours, Signal:10 minutes
Audible Range*
3
(approx.)
Voice: 125 m
Voice: 250 m
Voice: 250 m, Signal: 315 m
Magnetic Circuit
Neodymium magnet, inner magnet type
Diaphragm
Polyimide film (voice coil, bobbin)
Anti-bacteria Treatment
Mouth and handle
Water protection
IPX5
Operating Temperature
–10 to +40°C
Finish
Horn
ASA resin,
ASA resin,
ASA resin,
ASA resin,
clear dark gray
clear dark gray
clear red
clear dark gray
Others
ASA resin, dark gray
ASA resin, dark gray
ASA resin, red
ASA resin, yellow
Dimensions
137 (w) x 257.8 (h) x 210 (d) mm
154 (w) x 266 (h) x 250 (d) mm
Weight (without batteries)
610 g
660 g
680 g
URL: http://www.toa.jp/
CAUTION
• Before pressing the talk switch, fully turn down
the volume.
• Point the megaphone toward the ground when
conducting operational tests.
7. USING THE HANDLE CAP
There is no problem in general use. But if high
impact is applied to the battery cover, it may open,
causing the battery case to drop.
When moving around hard with the megaphone in
hand, be sure to install the supplied handle cap as
shown below.
[When the handle cap
is installed]
2. Install the
handle cap.
1. Run the
string.
Handle cap
(accessory)
3. Install the handle cap so that its
projection can securely fit into
the battery cover's slot.
Handle cap
(accessory)
533-03-027-3H
