Toa AD-1215P - Manual

Power Source 100 to 240 V AC, 50/60 Hz
Output 12 V DC, 1.5 A
Current Consumption 500 mA (rated output)
Plug (Conductor) Center positive,
ø5.5 x ø2.1 x length 9.5 mm (0.37")
Operating Temperature 0 to +40°C (32 to 104ºF)
Finish Case: Polycarbonate, black
Weight 130 g (0.29 lb)
Note: The design and specifications are subject to change
without notice for improvement.
INSTRUCTION MANUAL
AC ADAPTER AD-1215P
Thank you for purchasing TOA's AC Adapter.
Please carefully follow the instructions in this manual to
ensure long, trouble-free use of your equipment.
1. GENERAL DESCRIPTION
The AD-1215P is a dedicated AC adapter to operate the
Packet Intercom IP Stations on AC power. Never use it for
other equipment.
2. SAFETY PRECAUTIONS
• Before installation or use, be sure to carefully read all the
instructions in this section for correct and safe operation.
• Be sure to follow all the precautionary instructions in this
section, which contain important warnings and/or
cautions regarding safety.
• After reading, keep this manual handy for future
reference.
5. SPECIFICATIONS
• Do not expose the unit to rain or an environment where it
may be splashed by water or other liquids, as doing so
may result in fire or electric shock.
• Use the unit only with the voltage specified on the unit.
Using a voltage higher than that which is specified may
result in fire or electric shock.
• Do not cut, kink, otherwise damage nor modify the power
supply cord. In addition, avoid using the power cord in
close proximity to heaters, and never place heavy objects
-- including the unit itself -- on the power cord, as doing
so may result in fire or electric shock.
• Should the following irregularity be found during use,
immediately, disconnect the power supply plug from the
AC outlet and contact your nearest TOA dealer. Make no
further attempt to operate the unit in this condition as this
may cause fire or electric shock.
· If you detect smoke or a strange smell coming from the
unit.
· If water or any metallic object gets into the unit
· If the unit falls, or the unit case breaks
· If the power supply cord is damaged (exposure of the
core, disconnection, etc.)
• To prevent a fire or electric shock, never open nor
remove the unit case as there are high voltage
components inside the unit.
• Never plug in nor remove the power supply plug with wet
hands, as doing so may cause electric shock.
• Avoid installing the unit in humid or dusty locations, in
locations exposed to the direct sunlight, near the heaters,
or in locations generating sooty smoke or steam as doing
otherwise may result in fire or electric shock.
• Remove the power supply plug from the AC outlet when
moving the connected equipment, as doing otherwise
may cause damage to the power cord, resulting in a fire.
• If dust accumulates in the wall AC outlet, a fire may
result. Clean it periodically.
• Unplug the power supply plug from the AC outlet for
safety purposes when cleaning or leaving the unit unused
for 10 days or more. Doing otherwise may cause a fire or
electric shock.
WARNING
CAUTION
Indicates a potentially hazardous situation which,
if mishandled, could result in death or serious
personal injury.
Indicates a potentially hazardous situation which,
if mishandled, could result in moderate or minor
personal injury, and/or property damage.
4. DIMENSIONAL DIAGRAM
30.5
(1.2)
17
(0.67)
8
(0.31)
1800 (70.87)
Unit: mm (in)
45 (1.77)
70 (2.76)
133-06-309-1A
URL: http://www.toa.jp/
3. CHECKUP AND REPLACEMENT
Periodical checkup and replacement are required to ensure
trouble-free use of the AC Adaptor. Replace it in about 6
years as a guide when used 24 hours every day under
normal use conditions. This 6-year period is suggested
only as a guide, and may be shortened depending on the
installation environment and conditions of use.
