Model Number

WT-5800

WT-5805

Power Source

120 V AC (Supplied AC-DC adapter must be used.)

Power Consumption

250 mA (12 V DC)

200 mA (12 V DC)

Receiving Frequency

636 – 698 MHz, UHF

Selectable Channel

64 selectable frequencies

Receiving System

Double super-heterodyne

Diversity System

Space diversity (true diversity)

Space diversity

AF Output

MIC/LINE: –60 dB* (MIC)/–20 dB* (LINE) selectable, 600 Ω
Phone jack (unbalanced), XLR-3-31 type connector (balanced)

AF Mixing Input

–20 dB*, 10 kΩ, unbalanced, phone jack

Antenna Input

75Ω, BNC (phantom powering for antenna), 9 V DC, 30 mA (max)

Antenna Output

75Ω, BNC (Gain 0 dB)

Receiving Sensitivity

Over 90 dB, S/N ratio (20 dBμV input, 40 kHz deviation)

Squelch Sensitivity

18 – 40 dBμV variable

Squelch System

Using together of noise SQ, carrier SQ and tone SQ

Tone Frequency

32.768 kHz

Indicator

Audio (6 steps), RF (6 steps), ANT A/B, Audio (peak), Battery alarm

Channel Check

Usable frequencies scanning

S/N Ratio

Over 110 dB (A-weight, unbalanced output)

Harmonic Distortion

Under 1% (typical)

Frequency Response

100 – 15000 Hz, ±3 dB

Operating Temperature

–10°C to +50°C

Finish Resin,

black

Dimensions

210 (w) x 44 (h) x 205.1 (d) mm

Weight 700

g

133-07-268-20

URL: http://www.toa.jp/

10. SPECIFICATIONS

* 0 dB = 1 V

Note: The design and specifications are subject to change without notice for improvement.

• Accessories
AC-DC adapter ........................................... 1

• Optional products
Mounting bracket kit: MB-WT3 (for rack mounting one WT-5800/5805 unit)

MB-WT4 (for rack mounting two WT-5800/5805 units)
