Toa WT-5805 - Manual (Page 11)

11
9. RACK MOUNTING
• When mounting one WT-5800/5805 unit, use an optional mounting kit MB-WT3.
Fiber washer * 1
(for M5)
Rack mounting screw * 1
5 x 12
AF P EAK BTT
ANT A
B
VO L
10
UP
SE T
DO W
PO WE R
UHF WIRELE
SS
DIV ER SIT Y W IRE LES S T UN ER W T-58 00
Bracket A * 1
Bracket B * 1
WT-5800/5805
Fiber washer * 2
(for M5)
Rack mounting screw * 2
5 x 12
Bracket * 2
WT-5800/5805
WT-5800/5805
AF P EAK BTT
ANT A
B
VO L
10
UP
SE T
DO W
PO WE R
UHF WIRELESS DIV ER SIT Y W IRE LES S T UN ER W T-5 800
AF P EAK BTT
ANT A
B
VO L
10
UP
SE T
DO W
PO WE R
UHF WIRELESS DIV ER SIT Y W IRE LES S T UN ER W T-5 800
Connector * 2
• When mounting two WT-5800/5805 units, use an optional mounting kit MB-WT4.
* 1 Component parts of the MB-WT3.
* 2 Component parts of the MB-WT4.
