Model No. ER-520 ER-520S ER-520W
Output Rated 6 W, Max. 10 W
Power Source AA (R6P) battery x 8 (12 V DC)
Signal – Siren Whistle
Battery Life* 1 Voice: 10 h Voice: 10 h Voice: 10 h
(approx.) – Signal:40 min Signal:30 min
Audible Range* 2 Voice: 250 m Voice: 250 m
(approx.) Signal: 315 m
Diaphragm Polyimide film
Operating Temperature –10 to +40°C
Finish Horn ABS resin, ABS resin, ABS resin,
Light gray Red Light gray
Others ABS resin, ABS resin,
Gray Gray
Dimensions 160 (w) x 256 (h) x 260 (d) mm
Weight
620 g 650 g
(without batteries)
• Before installation or use, be sure to carefully read all the
instructions in this section for correct and safe operation.
• Be sure to follow all the precautionary instructions in this
section, which contain important warnings and/or
cautions regarding safety.
• After reading, keep this manual handy for future
reference.
INSTRUCTION MANUAL
MEGAPHONES ER-520
ER-520S
ER-520W
Thank you for purchasing TOA's Megaphones.
Please carefully follow the instructions in this manual to ensure
long, trouble-free use of your equipment.
1. SAFETY PRECAUTIONS
2. GENERAL DESCRIPTION
Easy-to-operate 6 W handheld megaphones.
The ER-520S offers a siren switch, and the ER-520W is
equipped with a whistle switch.
The megaphones have a convenient carrying strap.
Handle and mouthpiece with anti-bacteria treatment improve
hygiene and safety during use.
3. HANDLING PRECAUTIONS
• The ER-520/520S/520W megaphones are not waterproof.
Avoid exposure to rain or environments where they may be
splashed by water or other liquids.
• Immediately contact your TOA dealer if the following
irregularities should occur. To avoid unit failure, make no
further attempt to use the unit in these conditions.
· Smoke coming from the unit or a strange smell detected.
· Water or other foreign objects get inside the unit.
· No sound heard (after checking to be sure that the batteries
are loaded in correct orientation, and satisfactorily charged).
• Avoid storing the unit in humid or dusty locations, in locations
exposed to direct sunlight, near heaters, or exposed to sooty
smoke, as these conditions may result in unit failure.
• When batteries are left installed in the megaphone for extended
periods of time, be sure to check them periodically for charge
and leakage.
• Do not use the unit for extended periods of time with a distorted
sound output. This could cause the inner parts to become hot
and possibly result in unit failure.
• Noise may be produced when a mobile phone is used near the
unit. However, this is not a failure. Use the mobile phone as far
as possible from the unit.
• Use a tightly wrung-out damp cloth to clean the unit. If the unit
becomes extremely dirty, use a cloth moistened in a neutral
detergent and tightly wrung-out. Never use volatile liquids such
as benzene, thinner, or alcohol to clean the unit, as these may
deform or discolor its case.
4. SPECIFICATIONS
* 1 Battery life estimates assume 30 minutes of continuous use
per day.
* 2 Audible range estimates assume use on a relatively quiet
street using new batteries and will vary depending on
remaining battery capacity, surrounding noise, wind direction,
obstacles and other environmental conditions.
Notes
• No accessory batteries are supplied.
• The design and specifications are subject to change without
notice for improvement.
CAUTION
Indicates a potentially hazardous situation which,
if mishandled, could result in moderate or minor
personal injury, and/or property damage.
• Cautions on Use
Be sure to observe the following instructions. Failing to
observe may cause hearing impairment.
· Reduce the volume to its lowest setting before use.
· Never use the megaphone in close proximity to a
person's ear.
· Point the megaphone toward the ground when
conducting operational tests.
• Make sure to observe the following handling precautions
so that a fire or personal injury does not result from
leakage or explosion of the battery.
· Do not short, disassemble, heat nor put the battery into
a fire.
· Avoid using both new and old batteries together.
· Never charge batteries of the type which are not
rechargeable.
· Do not solder a battery directly.
· Be sure to use the specified type of batteries.
· Note correct polarity (positive and negative orientation)
when inserting a battery in the unit.
· Avoid locations exposed to the direct sunlight, high
temperature and high humidity when storing batteries.
