Auxiliary hydraulic loader valve – Cub Cadet 6284 User Manual
Page 37
-37-
REF.
NO.
PART
NUMBER
DESCRIPTION
QTY.
1
603-0813
Pivot Bracket Assembly ...............
1
2
603-0862
Valve Handle Assembly ..............
1
3
703-05726
Fitting Mount Plate ......................
1
4
703-3598
Loader Valve Mount Bracket .......
1
5
703-3973
Rear Fitting Mount Plate .............
1
6
710-0501
Hex Screw, 1/4-20, 2.00, Gr5 .....
2
7
710-0599
Hex Wash. Hd. Tapp Screw ........
1/4-20 x .50
2
8
710-0604A
Hex Wash. Hd. Tapp Screw ........
5/16-18 x .625
2
9
710-1260A
Hex Wash. Hd. Tapp Screw ........
5/16-18 x .75
4
10
711-1611
Valve Pivot Shaft ........................
1
11
711-1624A
Valve Spool Link .........................
1
12
711-1637
Ball Joint Pivot Stud ....................
1
13
712-0324
Hex Lock Nut, 1/4-20, Gr8, Nylon
2
14
712-3025
Jam Nut, 5/16-24, Gr5 ................
2
15
713-3000 Chain
Link
...................................
1
16
715-0120
Spirol Pin, 3/16 x 1.0 ...................
1
17
716-0865 Snap
Ring,
.5
..............................
2
18
718-3140 Loader
Control
Valve
..................
1
19
723-0488
Ball Joint, .3125 Id x 5/16-24 ......
1
20
726-04046
Clamp, Hose ...............................
1
21
727-04088
Tube, Hydraulic - Boom Lift ........
1
22
727-04089
Tube, Hydraulic - Boom Lower ...
1
23
727-04090
Tube, Hydraulic - Bucket Rollback
1
24
727-04091
Tube, Hydraulic - Bucket Dump ..
1
25
727-3012
Fitting, 90° 6-6 Orb .....................
2
26
727-3224
Coupling, Male Hydraulic, 3/8-18
2
27
727-3225
Coupling, Female Hydr. 3/8-18 ...
2
28
727-3226
Tube, Auxiliary Pump Pressure ..
1
29
727-3227
Tube, Valve Pressure .................
1
30
727-3228
Tube, Valve Return .....................
1
31
727-3229
Tube, Valve Return .....................
1
32
727-3261
Plug, Hydraulic Coupler - Male ...
2
33
727-3262
Plug, Hydraulic Coupler - Female
2
34
731-3353
Knob, 1.625 Dia x 3/8-16 Thd
1
35
731-3374
Washer, Indicator - Red ..............
1
36
731-3375
Washer, Indicator - Yellow ..........
1
37
731-3376
Washer, Indicator - Green ...........
1
38
731-3377
Washer, Indicator - Blue .............
1
39
735-0696 Joystick
Boot
...............................
1
40
737-3112
Fitting, Straight -8 Orb .................
2
41
737-3125
Fitting, Straight - 6 Orb ................
2
42
737-3129
Fitting, Bulkhead 3/4-16 x 3/8-18
4
43
737-3130
Fitting, Bulkhead 3/4-16 x 3/4-16
2
44
750-0845
Spacer, .34 ID x .5 OD x .31 .......
1
AUXILIARY HYDRAULIC LOADER VALVE
