E-9
General Guide
1 POWER/MODE switch
2 MAIN VOLUME slider
3 SYNCHRO/FILL-IN button
4 START/STOP button
5 ACCOMP VOLUME button
6 TRANSPOSE/TUNE button
7 TEMPO buttons
8 Speakers
9 Song Bank list
0 Display
A Rhythm list
B Tone list
C CHORD root names
D Percussion instrument list
E RHYTHM button
F TONE button
G SONG BANK button
* Attachment of the Score Stand
Insert both ends of the music stand provided
with the keyboard into the two holes on the
top surface.
Rear Panel
Q PHONES/OUTPUT terminal
R DC 9.5V terminal
H [+]/[–] buttons
• Negative values can be changed only by using [+] and
[–] to increase and decrease the displayed value.
I Number buttons/Chord specification buttons
• For input of numbers to change displayed settings.
• For input of chord specification data when using the
Chord Book.
J REW button
K FF button
L STOP button
M PLAY/PAUSE button
N LEFT ON/OFF button
O RIGHT ON/OFF button
P CHORD button
Q R
