IMPORTANT: Remove all protective plastic film from
stainless steel parts prior to assembly/use. This film
is installed at the factory to prevent damage that
could occur during shipment and handling.
LEFT SHELF ASSEMBLY
1. Open the grill hood and place a piece of styrofoam from
the packaging under the grill hood to prop the grill hood
open slightly. (See Fig. 1)
2. Attach the left shelf by inserting the four shelf hooks into
the slots on the side of the grill. (See Fig. 1)
3. After inserting the four shelf hooks, press the shelf
against the grill and press downward until the shelf
locks in place. Make sure the top strip is hanging all the
way inside of the grill before pressing downward.
(See Fig. 1)
4. Install one self tapping screw into the bottom front hole
of the shelf to lock shelf in place. (See Fig. 2)
SIDE BURNER PARTS ASSEMBLY
1. Remove side burner assembly from packaging.
(See Fig. 3)
2. Place a piece of styrofoam from the packaging in the
grill to leave the grill hood propped open slightly.
(See Fig. 4)
3. Attach the right side burner by inserting the four shelf
hooks into the slots on the side of the grill. (See Fig. 4)
4. After inserting the four shelf hooks, press the side
burner shelf against the grill and press downward until
the shelf locks in place. Make sure the top strip is
hanging all the way inside of the grill before pressing
downward. (See Fig. 4)
4
Grill Assembly
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Top Strip
Top Strip
