Grill Assembly
SIDE BURNER PARTS ASSEMBLY
6. Remove the two phillips pan head M5 x 10 screws
to from the orifice bracket, then hold the orifice
bracket, make sure the orifice goes into the center
hole on the side burner bracket. (See Fig. 9)
7. Use two screws remvoed in step 6 to secure the
orifice backet on the side burner tray. (See Fig. 10)
Note: Add lock washer when installing the screws in
position.
8. Place the side burner grate in position. (See Fig.
11)
Note: Remove all the tape before using the grill.
9. Attach the igniter wires to the igniter terminals. It
does not matter which wire goes to which terminal
on the igniter module. (See Fig. 12)
10.Unscrew the igniter push button from the igniter
module, install the "AA" battery with positive end
facing out. Screw the push button back onto the
igniter. (See Fig. 13)
Fig. 9
Orifice bracket
Orifice
Side burner bracket
Fig. 10
Screws
Orifice bracket underneath the side burner tay
Fig. 11
Fig. 12
Fig. 13
8
