DW800/820 Operation Manual
COMMUNICATION
Page 13
Scoreboard Output Format
If the Scoreboard Output Format is to be used then the Output Format parameter must be set
to SCB
(See Parameter Setup)
.
The Scoreboard Output Format is as follows: Value CR LF
Name
Characters
Description
Value
7
Displayed weight or quantity
CR
1
ASCII Carriage Return (0D Hex)
LF
1
ASCII Line Feed (0A Hex)
External Control
External Keys
The serial interface allows an external device to transmit data (external keys) to the
DW800/820, which mimic the keypad operation completely.
External Key
ASCII Value
Hex Value
Decimal Value
ZERO
a
81
097
b
62
098
UNITS
c
63
099
TARE
d
64
100
GROSS/NET
9
67
103
PARAMETERS
z
7A
122
External Switch
An external switch is a hardware switch used to mimic a keypad operation completely. The
DW800/820 allows for only the ZERO external switch.
A momentary, normally open, switch must be connected between “Pin 01” and “Pin 09”.
External ZERO is activated when the switch is closed.
To avoid erratic operation the switch cable must be less than 10 feet.
_____________________________________________________________________________________________________________
Revision 4.3 Copyright ©2004 Sterling Scale Co., Inc. May 2004
