StarTech.com EC2000S - Manual (Page 6)

Instruction Manual
3
Specifications
Host Interface ExpressCard 1.0
Form Factor ExpressCard/34 (34mm)
Chipset ID Realtek RTL8111E
External Connectors 2 x RJ45 Ethernet female
LEDs
2 x Gigabit Link
2 x Link/Activity
Supported Standards
IEEE 802.3, IEEE 802.3u,
IEEE 802.3ab, IEEE 802.3x,
IEEE 802.1Q
Maximum Data Transfer
Rate
1000 Mbps
Auto MDIX Yes
Full Duplex Support Yes
Buffer Size 48 KB
Operating Temperature 0°C ~ 55°C (32°F ~ 151°F)
Storage Temperature -20°C ~ 85°C (-4°F ~ 185°F)
Humidity 5% ~ 95% RH
Dimensions 115.8mm x 34.0mm x 21.0mm
Weight 150g
Compatible Operating
Systems
Windows 2000/XP/Server 2003/Vista/Server 2008
R2/7 (32/64-bit), Mac OS 10.4/10.5, Linux
