3

Installation

POEINJ100

This should be the side that does not require Power over Ethernet.
1. Connect the Ethernet cable from the source network device (i.e.

computer, router, switch, etc) to the “Data (In)” RJ45 connector on the

input side of the POEINJ100 unit.

2. Connect the included power adapter to the POEINJ100 unit.
3. Connect an RJ45 terminated Ethernet cable to the “Power + Data (Out)”

connector on the output side of the POEINJ100 unit. The other end of

the cable will either connect directly to a PoE compliant device, or to the

POESPLT100 in order to separate data and power again.

POESPLT100

1. Connect the Ethernet cable from the POEINJ100 unit to the “Data +

Power (In)” RJ45 connector on the input side of the POESPLT100 unit.

2. Set the slide switch on the side of the unit to the desired voltage output

(5V, 7.5V, 9V, 12V).

3. Connect an RJ45 terminated Ethernet cable from the “Data (Out)”

connector on the output side of the POESPLT100 to the network device

(i.e. computer, router, switch, etc).

4. Connect the included Power Output Cable from the “Output Power”

connector on the output side of the POESPLT100 unit to the DC power

connector on the network device.
