StarTech.com POEINJ2GI - Manual (Page 9)

Instruction Manual
7
Specifications
Number of Ports 2
Industry Standards IEEE 802.3at PoE, IEEE 802.3af PoE
Regulatory Approvals
EMS: EN61000-4-2 (ESD), EN61000-4-3
(RS), EN61000-4-4 (EFT), EN61000-4-5
(Surge), EN61000-4-6 (CS), EN61000-4-8,
EN61000-4-11
Shock: IEC60068-2-27
Free Fall: IEC60068-2-32
Vibration: IEC60068-2-6 Safety: EN60950-1
Connector(s)
4 - RJ-45 Female
1 - Terminal Block (4 Wire) Female
Maximum Data Transfer Rate 1Gbps
Power Output 50V / 600mA, 30 Watts max. per port
Enclosure Type Steel
Power Adapter Terminal Block
Input Voltage 50 ~ 57 DC
Operating Temperature -40°C to 70°C (-40°F to 158°F)
Storage Temperature -40°C to 80°C (-40°F to 176°F)
Humidity 5~95% RH (Non-Condensing)
Dimensions 95 x 70 x 26 mm
Weight 212g
