StarTech.com ST7300U3M - Manual

Instruction Manual
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Manual Revision: 11/20/2014
For the most up-to-date information, please visit: www.startech.com
Packaging Contents
• 1x USB 3.0 Hub
• 1x USB 3.0 A - B Cable
• 1x Wall-Mount Bracket (w/ Screws)
• 2x Rubber Footing Strips
• Universal Power Adapter (NA+JP/UK/EU/AUS)
• 1x Instruction Manual
System Requirements
• USB enabled computer system with an available USB port
• Available AC electrical outlet (optional, but required for high-
power USB devices)
• OS Independent
Product Overview
Front View
Side View
ST7300U3M
7 Port Compact Metal USB 3.0 Hub - Desktop or Wall-Mountable
*actual product may vary from photos
Hub Port LEDs USB 3.0 Hub Ports
DC Input USB 3.0 Host Port
Installation and Operation
Supplying external power is optional, however, to ensure that
each USB port is fully powered, connecting external power is
recommended.
1. Using the appropriate Power Plug for your region, connect the
provided Power Adapter to an AC electrical outlet, and then
connect the Power Adapter to the DC Input on the hub - the hubs
power LED should be lit amber.
2. Using the provided USB 3.0 A - B cable, connect the hubs USB 3.0
host port to an available USB port on your host computer system.
Note: If connected to a USB 2.0 host port, the hub will only operate
at USB 2.0 speeds.
3. Your computers operating system should detect the USB hub and
automatically install it.
4. Connect your USB peripherals to the USB 3.0 hub ports - when
devices are connected, the corresponding LED (1 to 7) should be
lit amber.
Side View
Power LED
