StarTech.com ST7300USB3B - Manual

Instruction Manual
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Manual Revision: 01/20/2014
For the most up-to-date information, please visit: www.startech.com
Packaging Contents
• 1x USB 3.0 Hub
• 1x USB 3.0 Cable
• 1x Universal Power Adapter (NA/ UK/ EU)
• 1x Instruction Manual
System Requirements
• USB-enabled computer system with an available USB port
• Available AC power outlet (optional)
• Windows® 8 (32/64bit), 7 (32/64), Vista(32/64), XP(32/64),
Windows® Server 2012, 2008 R2, 2003(32/64), Mac OS 10.x (Tested
up to 10.9), Linux®
ST7300USB3B
7 Port SuperSpeed USB 3.0 Hub
*actual product may vary from photos
Installation
Note: Supplying external power is optional, however to ensure
that each USB port is fully powered, connecting external power is
recommended.
1. If not using external power, skip to Step 3.
2. Connect the included power adapter to an AC outlet, then to the
USB hub. The USB port LEDs (blue) will only turn on if you have a
device connected.
3. Connect the included USB A-B cable from the USB Hub (type-B
port) to the host computer system.
NOTE: If connected to a USB 2.0 host port, the hub will only
operate at USB 2.0 speeds.
4. The operating system should detect the USB Hub immediately
and automatically install it.
5. Once installation is complete, USB devices should be able to be
connected to the hub and recognized.
USB 3.0 Type A Ports
USB 3.0 Host Port DC Jack
Product Overview
