Instruction Manual 7
Specifications
SATDOCK4U2E SATDOCK4U3E
Number of Drives 4
Bus Interface
USB 2.0
SATA revision 2.x USB 3.0
SATA revision 2.x
Chipset ID Initio INIC1610P JMicron JM321 + JM539
External Connectors
2 x USB type A female
4 x eSATA female
1 x USB 3.0 type B
female
1 x eSATA female
LEDs
4 x Drive Power
4 x Drive Activity
Fans 2 x 60mm
Maximum Data Transfer
Rate
USB 2.0: 480Mbps
eSATA: 3Gbps USB 3.0: 5Gbps
eSATA: 3Gbps
Hard Drive Compatibility
2.5”/3.5” SATA 1.5/3.0/6.0 Gbps compatible drives,
tested up to 2.0TB in capacity
Insertion Rating 15, 000 cycles
Power Adapter 12VDC, 6500mA
Operating Temperature 5°C ~ 80°C (41°F ~ 176°F)
Storage Temperature -40°C ~ 70°C (-40°F ~ 158°F)
Humidity 8% ~ 90% RH
Dimensions 290.5mm x 172.7mm x 94.7mm
Weight 1054g 1020g
Compatible Operating
Systems
Windows 2000/ XP(32/64-bit)/ Server 2003(32/64-
bit)/ Vista(32/64-bit)/ 7(32/64-bit)/ Server 2008 R2,
Mac OS X, and Linux
