StarTech.com S3520WU33ER - Manual (Page 9)

Instruction Manual
6
Configure RAID
RAID Modes
JBOD JBOD
COMBINE Span (Big)
MIRRORING RAID1
STRIPING RAID0
Set RAID
1. Turn off the unit, by Pushing the Power button on the front panel.
2. Set the RAID switch to the RAID mode of your choice.
3. Press and hold the “Set RAID button” as you power on the enclosure by pressing the
“Power button”.
4. Once the enclosure has turned on, release the “Set RAID button”.
5. Your Desired RAID configuration is now set.
Note: When changing RAID configuraitons, follow the above steps to set the unit back
to JBOD (JBOD), before setting to a different configuration.
