Instruction Manual

1

Introduction

ID

Name

Qty

Rack Components

1

Left Vertical Rail

2

2

Right Vertical Rail

2

3

Base Bracket

2

4

Corner Section

8

5

Center Section

4

6

Top Bracket

2

Rack Assembly Hardware

10

M8 Bolt

48

11

M8 Washer

48

Rack Assembly Tool

12

M8 (13mm) Wrench

1

13

M6 (10 mm) Wrench

1

14

Phillips Screwdriver

1

Equipment Mounting Hardware

15

M6 Cage Nut

50

16

PVC Cup Washer

50

17

M6 Phillips-Head Screw

50

Cable Management Hardware

18

Cable Management Hook

24

19

Hook Mounting Screw

24

Casters and Hardware

20

Casters

4

21

Levelling Feet

4

22

M6 Screw

16

23

M6 Flat Washer

16

24

M6 Flange Nut

16

25

Grounding Wires

4

10

11

12

15

16

17

13

14

18

19

20

21

22

23

24

2

2

1

3

4

4

4

4

4

4

4

5

5

5

5

6

6

20

21

25
