Instruction Manual

4

LEDs

LEDs

Description

Status

• Solid green indicates ready status.
• Flashing green indicates the unit is

booting up.

• Off indicates no power.

Link

• Solid green indicates a connection

between the Local and Remote units.

• Off indicates no connection between

the Local and Remote units.

Video

• Solid green indicates a connection

to the Remote unit and the Host

computer.

• Flashing green indicates a video

signal from the Host computer is

being transmitted.

• Solid amber indicates that no video

source is connected to the Local unit

or no monitor isconnected to the

Remote unit.

• Flashing amber indicates an

incompatible video resolution is

detected.

• Off indicates no connection between

the Local and Remote units.

USB

• Solid green indicates a successful USB

connection to the Host computer.

• Flashing green indicates USB data

transmission.

• Solid amber indicates no USB

connection to the Host computer.

• Flashing amber indicates over-

current (short) on one of the USB

connections.

• Off indicates no connection between

the Local and Remote units.
