StarTech.com SV231DPU - Manual (Page 7)

Instruction Manual 4
5. OPTIONAL: Connect any other USB peripherals you wish to share between the connected
computers/devices to the extra USB Hub port on the Console side.
6. Connect the external power adapter from a wall outlet to the power connector on the rear
panel of the KVM switch.
7. Power up the first computer/device and wait for it to fully boot and test keyboard/mouse
functionality.
8. Once operation has been successfully confirmed, switch to the next port and power up that
computer/device and confirm.
9. Once completed for all computers/devices connected to the KVM switch, you should be able
to switch between any ports freely.
Driver Installation
No driver installation is required for the KVM switch, as the keyboard and mouse use generic USB
keyboard/mouse drivers that are already installed on any operating system that fully supports
USB.
Operation
Front Panel
PC Link/Selection LED
The LED turns green when the connected computer is powered-on. The corresponding LED will
also illuminate red when that PC port is currently selected.
Port Selection Button
Pushing the front panel “Select” button toggles between the PC ports on the KVM switch.
