Instruction Manual 5
Operation
Front Panel
Port Selection/Link LED
The LED turns green when the connected computer is powered-on. The corresponding LED will
also illuminate red when that PC port is currently selected.
Port Selection Button
Each push of the Selection Button on the front of the KVM switch will immediately switch
between the two ports on the KVM switch.
Hotkey Control
A Hotkey command is a short keyboard sequence for selecting a computer, activating computer
scan, etc. A hotkey sequence starts with two left keystrokes (successively within 0.2
seconds) followed by one or two more keystrokes. A built-in tone generator creates a high-pitch
beep for correct hotkey command; otherwise, one low-pitch beep is generated for errors and the
bad key sequence will not be forwarded to the selected computer.
NOTE: Press and hold Left and press twice, then release followed
by pressing left once, which will enable / disable the hotkey feature.
To select a computer:
Left + Left + <1>
(Example: Selects the computer at port 1.)
Left + Left + <2>
(Example: Selects the computer at port 2.)
NOTE: Do not use the keypad on the right-side of the keyboard.
