ILLUSTRATION C
NOTE: It is important to replace the self-sharpening point on the auger when it shows signs of excessive wear.
Generally, the digging life of the point will be greater than that of the inner cutting edge. The digging life of
the inner cutting edge will be greater than that of the outer cutting edge since it covers fewer inches of
digging circumference.
CUTTING EDGES AND POINT PARTS BREAKDOWN
REFERENCE NUMBER
SKU
DESCRIPTION
NUMBER REQUIRED
1
S24056700
6 in. cutting edge
2
2A
S24057700
9 in. outer cutting edge
1
2B
S24057800
9 in. inner cutting edge
1
3
S24058700
12 in outer cutting edge
1
4
S24058800
12 in. inner cutting edge
1
5
S24059200
Screw point with 1-1/4 in. NC threads
1
6
O/L
3/8 in. NC x 1-1/4 carriage bolt
4
7
O/L
3/8 in. lockwasher
4
8
O/L
3/8 in. NC hex nut
4
O/L - Obtain locally. Common fasteners available through hardware and farm stores.
