PARTS BREAKDOWN FOR S241003C0 HAND HELD DIGGER
REFERENCE
NUMBER
PART NUMBER
DESCRIPTION
NUMBER
REQUIRED
S241003C0
Two-Man Earth Auger
1
A
S24123300
Gear Box
1
1
O/L
M6 x 40 Bolt
2
2
O/L
M6 x 60 Bolt
4
3
--
Output Shaft
1
4
--
Ball Bearing - 6004
3
5
--
Reducer Case
1
6
--
Ball Bearing - 6202
2
7
--
Snap Ring - 20
2
8
--
Pinon Gear
1
9
--
Gear
1
10
--
Dowel Pin - 6 x 12
1
11
--
Gear
1
12
--
Dowel Pin - 5 x 12
1
13
--
Pinon Gear Threaded
1
14
--
Snap Ring - 16
1
15
--
Reducer Cover
1
16
S2415300
Clutch Drum
1
17
--
Handle Frame
1
18
O/L
M8 - Nut
8
19
O/L
M8 x 35 - Bolt
8
20
S24125600
Handle
4
21
S24125700
Rubber Sleeve
4
22
O/L
M6 - Nut
1
23
S24125500
Throttle Control
1
24
O/L
Semi-Circle-Head-Bolt - M6 x 50
1
25
S24125400
Throttle Cable
1
26
O/L
M8 x 30 - Bolt
2
27
O/L
M8 x 60 - Bolt
1
28
--
Adaptor Base
1
