Speeco S401635PH User Manual
Page 14
Page 12
TONGUE ASSEMBLY BREAKDOWN
ITEM NO. PART NO.
DESCRIPTION
QTY.
1
S17280300
M10 x 1.5 Nylock Nut
2
2
S17271600
M10 x 1.5 x 100mm GR5 Bolt
1
3
S17272000
M10 x 1.5 x 120mm GR5 Bolt
1
4
S17290800
M10 Flat Washer
6
6
5
S40127200
Tongue with Jack
1
1
6
S40034600
Hitch Ball Assembly
1
7 S40032300
Safety
Chain
2
WHEEL REPLACEMENT PARTS
ITEM NO.
PART NO.
DESCRIPTION
QTY.
2
S400312B0
Tire & Wheel Assembly
1
3
O/L
3/4” Light Flat Washer
1
4
S17012000
3/4” Slotted Nut
1
5
O/L
1/8” x 1-1/2” Cotter Pin
1
6
S40032200
Hub Cap
1
-
S40030900
Replacement Wheel Bearing Kit (not shown) 1
-
S40170400
Fender (not shown)
1
-
S40116800
Hardware Kit for Log Splitter (not shown)
1
O/L- Obtain locally. Common fasteners available through hardware and farm stores.
