Backpage Parameters | 9
AS – Auto-Scroll: This parameter enables/disables the auto-scroll func-
tion. When in auto-scroll mode, the footswitch preset scroll will continue
to scroll automatically even after the footswitch is released. This can be
a fun way to get unique tremolo or sequencer sounds as the unit steps
through the four equalizer presets at a given programmable rate. The
rate of the scrolling is controlled by the switching speed (SW) parameter.
Auto-scrolling will stop when the footswitch is pressed again. Like the
OE function, this parameter uses the two bottom LEDs on the display to
indicate ON or OFF.
MC – MiDi Channel: Use this parameter to edit the MIDI channel for the
Programmable EQ. The display will numerically indicate the currently
selected channel from 1 to 16.
Note: Backpage parameters can be reset to factory default values by
pressing both band select left and right buttons simultaneously.
125 250 500 1K 2K 4K 8K
+18
-18
0
+18
-18
0
1 2 3 4
SAVE SELECT
OUTPUT
ON/OFF
(HOLD)
PRESET SELECT
62 125 250 500 1K 2K 4K
PROGRAMMABLE EQ
OE SW MC AS
BP
PRESS PRESS
125 250 500 1K 2K 4K 8K
+18
-18
0
+18
-18
0
1 2 3 4
SAVE SELECT
OUTPUT
ON/OFF
(HOLD)
PRESET SELECT
62 125 250 500 1K 2K 4K
PROGRAMMABLE EQ
OE SW MC AS
Off
On
