BACkPAGE PARAMETERS
The Programmable EQ features an additional set of functions called
Backpage Parameters. These features can be accessed in Backpage
mode only. In this mode, the equalizer display takes on some secondary
functionality.
To enter Backpage mode, press the left arrow band select button and the
SAVE button simultaneously. The display will change to reflect the current
Backpage parameter settings. Like an equalizer band, use the left and
right buttons to select a column and use the encoder to change the value.
Backpage mode can be exited by pressing both save and left select but-
tons together again.
Backpage Parameters | 7
125 250 500 1K 2K 4K 8K
+18
-18
0
+18
-18
0
1 2 3 4
SAVE SELECT
OUTPUT
ON/OFF
(HOLD)
PRESET SELECT
62 125 250 500 1K 2K 4K
PROGRAMMABLE EQ
OE SW MC AS
BP
PRESS
PRESS
Backpage parameter labels
