I N S T R U C T I O N M A N U A L • M O D E L G X E P O W E R S U P P LY
33
A P P E N D I X
Item 1: Using the first line of the sample listing above, item 1 is the
“Customer Resettable Counter” (CRC). It is located at position 1 through
position 6 so the value of 005647 indicates that the last cycle was weld
number 5647 since the last time it was reset to 0 (see page 19).
005647 00.48 sec 0.025 in 000130 J 045 %Pmax Alarms T:-- D:-- E:-- J06 -----
Item 2: The second item sent is the actual weld time from the last cycle –
the time that the ultrasonic generator was running. So 00.48 means that the
generator was ON for .48 seconds. If the weld cycle finished its programmed
weld time, then the following “sec” would have been transmitted as upper
case letters or “SEC.” The “sec” is lower case so the weld cycle was
terminated through some other parameter. The time data is located at
positions 8 through 12 and includes the “.” at position 10. The “sec” label is
located at position 14 through position 16. Space characters are located at
positions 7, 13 and 17.
005647 00.48 sec 0.025 in 000130 J 045 %Pmax Alarms T:-- D:-- E:-- J06 -----
Item 3: Next is the distance data. Distance controls are not available on
Model GXE, so the Distance data will always appear as 0.000 in or 00.00
mm.
005647 00.48 sec 0.000 in 000130 J 045 %Pmax Alarms T:-- D:-- E:-- J06 -----
Item 4: Energy data is located at positions 27 through 32. The energy
number is the total Joules (watt-seconds) delivered to the load during the last
weld cycle. The following label “J” is an upper case letter (position 34) that
means this cycle was terminated because the energy setpoint was achieved
terminating the weld. If the cycle had not been terminated by energy control,
the label would have been a lower case character “j.” Space characters are
located at positions 33 and 35.
005647 00.48 sec 0.025 in 000130 J 045 %Pmax Alarms T:-- D:-- E:-- J06 -----
PRINT LINE OUTPUT DATA ITEMS
NOTE: Refer to page 26
for additional Print Line
Output.
