I N S T R U C T I O N M A N U A L • M O D E L G X E P O W E R S U P P LY

5. DISTANCE key. Option not available with Model GXE.

6. ENERGY key which allows selection and display of the following energy

settings and permits adjustment of the energy parameters a. through c.

below in 1 joule increments (from 0 to 999,999 joules):

a. Energy Setting

b. Energy Limit Low

c. Energy Limit High

d. Calibration Pulse (on/off)

For a complete explanation of these parameters, refer to page 21.

7. AMPLITUDE/PRESSURE key which controls adjustment of the

following amplitude and pressure settings of the system’s high-frequency

vibrations over the full operating range. (Major adjustments of amplitude

can be made through the use of different boosters – consult your press

manual for further information.)

a. Amplitude Setting

b. Amplitude Ramp (only on systems configured for more than 2200

watts)

c. Trigger Force (Press)

8. TRIGGER key which displays and permits selection of the trigger mode

from the following options –

a. Delay Timer

b Force/Pressure

c. Pretrigger - Top

9. RECALL/SAVE key which allows up to 15 different jobs to be stored

(saved) and recalled or changed upon demand.

10. ARROW keys (Up/Down) which allow scrolling through some menus and

also serve as a toggle for displayed parameter options in some menus.

11. TEST key which can be used to test ultrasonic operation and displays

idle losses of converter/booster/horn as a percentage of maximum power

when key is depressed. Also functions as a frequency display.

12. O.L. RESET key which resets the power supply following an overload

condition. Red LED in upper left corner indicates an overload condition

exists.

13. 0-9 NUMERIC KEY PAD which allows input of numeric data or

numeric selection options by pressing the keys.
