SerialGate User Guide
Software
Protocol TCP, UDP, ICMP, DHCP, HTTP
Utility Redirector, TestView
Configuration from Web, SGConfig
Ordering Information
SG-1010/232-RJ 1 x Serial RJ-45 Port (RS232 only)
SG-1010/Combo-RJ 1 x Serial RJ-45 Port (RS422/RS485 selectable)
SG-1010/ALL 1 x Serial DB-9 & T/B Port (RS232/RS422/RS485 selectable)
SG-1010W/ALL 1 x Serial DB-9 & T/B Port (RS232/RS422/RS485 selectable)
SG-1020/232-RJ 2 x Serial RJ-45 Port (RS232 only)
SG-1020/Combo-RJ 2 x Serial RJ-45 Port (RS422/RS485 selectable)
SG-1020/ALL 2 x Serial DB-9 & T/B Port (RS232/RS422/RS485 selectable)
SG-1020W/ALL 2 x Serial DB-9 & T/B Port (RS232/RS422/RS485 selectable)
SG-1040/232 Series 4 x Serial RJ-45 Port (RS232 only)
SG-1040/Combo Series 4 x Serial RJ-45 Port (RS422/RS485 selectable)
SG-1080/232 Series
8 x Serial RJ-45 Port (RS232 only)
SG-1080/Combo Series
8 x Serial RJ-45 Port (RS422/RS485 selectable)
SG-1160/ALL
16 x Serial RJ-45 Port (RS232/RS422/RS485 selectable)
SG-3011DCL/232
1 x Serial RJ-45 Port (RS232 only)
SG-3011PCL
1 x Serial Pin Header
(RS232, RS-422/485, TTL selectable)
32
