Vacuum Inlet Filters (Metric) March, 2000
Page 7
SOLBERG
Pipe Size
(inches)
Max Airflow
Pipe Size
(inches)
Max Airflow
Pipe Size
(inches)
Airflow
1/4" 10 m
3
/h 1 ¼" 102 m
3
/h 6" 1870 m
3
/h
3/8" 14 m
3
/h 1 ½" 136 m
3
/h 8" 3060 m
3
/h
1/2" 17 m
3
/h 2" 230 m
3
/h 10" 5610 m
3
/h
3/4" 34 m
3
/h 2 ½" 332 m
3
/h 12" 7990 m
3
/h
1" 60 m
3
/h 3" 510 m
3
/h 14" 10200 m
3
/h
4" 884 m
3
/h
5" 1360 m
3
/h
*Note: This information is for general use only. A qualified engineer must properly design each system.
3. Element Specifications
Media Micron Rating
Temperature
Range
Filter Change-Out
Differential
Standard Paper 99+% @ 2 micron -26 to 105 C 250-380 mm H
2
O
Over Initial Delta P
Standard
Polyester 99+% @ 5 micron -26 to 105 C 250-380 mm H
2
O
Over Initial Delta P
“N” Series 99+% @ 4 micron -26 to 105 C 250-380 mm H
2
O
Over Initial Delta P
“Z” Series 99+% @ 1 micron -26 to 105 C 250-380 mm H
2
O
Over Initial Delta P
HEPA “HE” Series 99.97% @ 0.3
microns
-26 to 105 C 250-380 mm H
2
O
Over Initial Delta P
“U” Series 99+% @ 25
micron -26 to 105 C 250-380 mm H
2
O
Over Initial Delta P
“W” Series 99+% @ 100
micron -26 to 105 C 250-380 mm H
2
O
Over Initial Delta P
“S1” Series Stainless Steel
Wire Mesh -26 to 105 C 250-380 mm H
2
O
Over Initial Delta P
“AC” & “ACP”
Series N/A -26 to 105 C 250-380 mm H
2
O
Over Initial Delta P
“Y” Series
Polypropylene 99+% @ 10
micron -26 to 105 C 250-380 mm H
2
O
Over Initial Delta P
“MX” & “MXD”
Series – Nomex
Cloth 99+% @ 10
micron -26 to 105 C 250-380 mm H
2
O
Over Initial Delta P
