Vacuum Inlet Filters (Metric) March, 2000
Page 10
SOLBERG
5. Securing canister top to canister base.
A. Make sure all surfaces are free from dust and other particulate.
B. Hemisphere o-ring must rest evenly along canister/casting base o-ring
groove.
C. VS/VL: Secure V-clamp by disconnecting hex nut or T-bolt portion and
placing V-clamp along the diameter of canister o-ring groove. Fasten T-
bolt and secure tightly. V-CLAMP LEGS MUST REST UNIFORMLY
ALONG ENTIRE O-RING GROOVE.
D. CT/Small CSL/CBL: Hold canister housing against o-ring or sealing ring
on main filter head. Re-fasten wire-form clips.
E. Large CSL: Replace housing top plate. Feed T-bolts into corresponding
slots and tighten evenly around perimeter. Note: Do NOT over tighten!
F. CSS: Reassemble top housing to bottom housing by aligning tabs and
turning into place.
Section D
MAINTENANCE RECOMMENDATIONS
1. Pressure drop readings are recommended to have an effective air filter.
Always document initial pressure drop during start-up when element is clean.
Replacement cartridge is needed when system experiences 250 mm to
380 mm H
2
O higher pressure drop above the initial reading. Refer to page 4
for instructions.
2. Always check replacement cartridge gaskets to insure they are adhered
uniformly along the end caps during handling. If not, contact Solberg
Manufacturing, Inc. immediately. Do not modify or change from Solberg
specified parts!
3. Always check inlets/outlets, element base and its components when replacing
element to insure cleanliness. Wipe clean if necessary.
4. Operate only when a proper seal exists.
5. VS/VL: Never operate without absolute assurance that V-clamp is secured
correctly along entire diameter of canisters. Check along V-clamp for wear.
Replace if any distortion occurs due to handling and usage.
